DRV8843 Series
Manufacturer: Texas Instruments
Beta
⌘K
45-V, 2.5-A BIPOLAR STEPPER OR DUAL H-BRIDGE MOTOR DRIVER WITH CURRENT REGULATION AND PWM CONTROL
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Interface | Motor Type - AC, DC | Voltage - Supply [Max] | Voltage - Supply [Min] | Supplier Device Package | Applications | Motor Type - Stepper | Package / Case [custom] | Package / Case | Package / Case [custom] | Function | Output Configuration | Voltage - Load [Max] | Voltage - Load [Min] | Technology | Current - Output | Embedded | Embedded | Type | Secondary Attributes | Primary Attributes | Supplied Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 150 °C | -40 °C | Surface Mount | Parallel | Brushed DC | 45 V | 8.2 V | 28-HTSSOP | General Purpose | Bipolar | 4.4 mm | 28-PowerTSSOP | 0.173 " | Driver - Fully Integrated Control and Power Stage | Half Bridge (4) | 45 V | 8.2 V | Power MOSFET | 1.75 A | |||||||
 Texas Instruments | Motor Controller/Driver | 16-Bit MCU | Power Management | Graphical User Interface (GUI) | Dual Full-Bridge (H-Bridge) Driver with PWM Current Controller | Board(s) | DRV8843 |
