307-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 84POS 0.156
| Part | Material - Insulation | Termination Rows | Color | Contact Finish | Number of Rows [custom] | Contact Type | Contact Material | Read Out | Mounting Type | Termination | Number of Positions [custom] | Card Type | Pitch | Pitch | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Positions | Number of Positions/Bay/Row [custom] | Features | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Gold | 2 | Semi Bellows | Copper Alloy | Dual | Right Angle Through Hole | Wire Wrap | 84 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Polyester Thermoplastic | Green | Tin | 2 | Semi Bellows | Copper Alloy | Dual | Right Angle Through Hole | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 2 | 42 | 21 | Card Guides | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Gold | 2 | Semi Bellows | Copper Alloy | Dual | Right Angle Through Hole | Wire Wrap | 84 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Tin | 2 | Semi Bellows | Copper Alloy | Dual | Right Angle Through Hole | Solder | 84 | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Gold | Semi Bellows | Copper Alloy | Single | Through Hole | Wire Wrap | Non Specified - Single Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 42 | Card Guides | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Gold | Semi Bellows | Copper Alloy | Single | Right Angle Through Hole | Solder | Non Specified - Single Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 42 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | Green | Tin | 2 | Semi Bellows | Copper Alloy | Dual | Through Hole | Solder | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 2 | 42 | 21 | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Gold | Semi Bellows | Copper Alloy | Single | Through Hole | Solder | Non Specified - Single Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 42 | 1 | |||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Tin | Semi Bellows | Copper Alloy | Single | Through Hole | Wire Wrap | Non Specified - Single Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 42 | Card Guides | 1 | ||||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Green | Tin | Semi Bellows | Copper Alloy | Single | Right Angle Through Hole | Solder | Non Specified - Single Edge | 3.96 mm | 0.156 in | 42 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 4-40 Flush Mount Threaded Insert Top Opening | 42 | Card Guides | 1 |
