DF37B Series

Catalog

CONN HDR 40POS SMD GOLD

Part	Contact Finish	Mounting Type	Height Above Board [z]	Height Above Board [z]	Number of Positions	Pitch	Pitch	Features	Mated Stacking Heights	Connector Type	Number of Rows [custom]	Number of Positions [custom]	Height Above Board	Height Above Board	Contact Finish Thickness	Contact Finish Thickness
Hirose Electric Co Ltd DF37B-40DP-0.4V(51)	Gold	Surface Mount	0.75 mm	0.03 in	40	0.4 mm	0.016 in	Solder Retention	0.98 mm	Header Outer Shroud Contacts	2
Hirose Electric Co Ltd DF37B-34DP-0.4V(51)	Gold	Surface Mount	0.75 mm	0.03 in		0.4 mm	0.016 in	Solder Retention	0.98 mm	Header Outer Shroud Contacts	2	34
Hirose Electric Co Ltd DF37B-20DS-0.4V(74)	Gold	Surface Mount			20	0.4 mm	0.016 in	Solder Retention	0.98 mm	Receptacle Center Strip Contacts	2		0.038 in	0.97 mm	0.1 Ám	4 Áin
Hirose Electric Co Ltd DF37B-16DS-0.4V(75)	Gold	Surface Mount			16	0.4 mm	0.016 in	Solder Retention	0.98 mm	Receptacle Center Strip Contacts	2		0.038 in	0.97 mm	0.1 Ám	4 Áin
Hirose Electric Co Ltd DF37B-16DP-0.4V(53)	Gold	Surface Mount	0.75 mm	0.03 in	16	0.4 mm	0.016 in	Solder Retention	0.98 mm	Header Outer Shroud Contacts	2
Hirose Electric Co Ltd DF37B-50DP-0.4V(75)	Gold	Surface Mount	0.75 mm	0.03 in	50	0.4 mm	0.016 in	Solder Retention	0.98 mm	Header Outer Shroud Contacts	2				0.1 Ám	4 Áin
Hirose Electric Co Ltd DF37B-24DS-0.4V(75)	Gold	Surface Mount			24	0.4 mm	0.016 in	Solder Retention	0.98 mm	Receptacle Center Strip Contacts	2		0.038 in	0.97 mm	0.1 Ám	4 Áin
Hirose Electric Co Ltd DF37B-34DP-0.4V(73)
Hirose Electric Co Ltd DF37B-40DS-0.4V(74)	Gold	Surface Mount			40	0.4 mm	0.016 in	Solder Retention	0.98 mm	Receptacle Center Strip Contacts	2		0.038 in	0.97 mm	0.1 Ám	4 Áin
Hirose Electric Co Ltd DF37B-40DP-0.4V(73)
