SP8M6 Series

Catalog

MOSFET N/P-CH 30V 5A 8SOP

Part	Drain to Source Voltage (Vdss)	Vgs(th) (Max) @ Id	Input Capacitance (Ciss) (Max) @ Vds [Max]	Package / Case	Package / Case	Package / Case	Supplier Device Package	Current - Continuous Drain (Id) @ 25°C	Power - Max [Max]	FET Feature	Configuration	Mounting Type	Operating Temperature	Gate Charge (Qg) (Max) @ Vgs [Max]	Rds On (Max) @ Id, Vgs [Max]	Technology	Gate Charge (Qg) (Max) @ Vgs	Input Capacitance (Ciss) (Max) @ Vds
Rohm Semiconductor SP8M6TB	30 V	2.5 V	230 pF	0.154 in	8-SOIC	3.9 mm	8-SOP	3.5 A 5 A	2 W	Logic Level Gate	N and P-Channel	Surface Mount	150 °C	3.9 nC	51 mOhm	MOSFET (Metal Oxide)
Rohm Semiconductor SP8M6HZGTB	30 V	2.5 V		0.154 in	8-SOIC	3.9 mm	8-SOP	3.5 A 5 A	2 W		N and P-Channel	Surface Mount	150 °C		51 mOhm 90 mOhm	MOSFET (Metal Oxide)	3.9 nC 5.5 nC	230 pF 490 pF
