PSK-S5B Series

DIN Rail Power Supplies 3.3W 3.3V 1000mA DIN-rail Mount

Manufacturer: CUI Inc.

Catalog

DIN Rail Power Supplies 3.3W 3.3V 1000mA DIN-rail Mount

Catalog

DIN Rail Power Supplies 3.3W 3.3V 1000mA DIN-rail Mount

Part	Current - Output 1	Voltage - Input [Min]	Voltage - Input [Max]	Number of Outputs	Voltage - Output 1	Approval Agency	Applications	Type	Mounting Type	Power (Watts)	Standard Number	Efficiency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Isolation	Features	DC Voltage - Input (Min) [Min]	Input Type	DC Voltage - Input (Max) [Max]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Current - Output (Max) [Max]	Package / Case	Load Regulation	Line Regulation	Current - Output 1 [custom]
CUI Inc. PSK-S5B-9-T	560 mA	85 VAC 100 V	264 VAC 370 VDC	1	9 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	77 %	31.5 mm	1.06 in	76 mm	26.8 mm	2.99 in	1.24 in	4000 V	Universal Input
CUI Inc. PSK-S5B-3-T	1 A	85 VAC 100 V	264 VAC 370 VDC	1	3.3 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	3.3 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	68 %	31.5 mm	1.06 in	76 mm	26.8 mm	2.99 in	1.24 in	4000 V	Universal Input
CUI Inc. PSK-S5B-5-T	1 A	85 VAC 100 V	264 VAC 370 VDC	1	5 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	75 %	31.5 mm	1.06 in	76 mm	26.8 mm	2.99 in	1.24 in	4000 V	Universal Input
CUI Inc. PSK-S5B-3-L	1 A	85 VAC 100 V	264 VAC 370 VDC	1	3.3 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	3.3 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	68 %	24.5 mm	0.71 in	37 mm	18 mm	1.46 in	0.96 in	4000 V	Universal Input
CUI Inc. PSK-S5B-9-DIN				1	9 V	CB Scheme EN IEC UL	ITE (Commercial)			5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	77 %	31.5 mm	1.24 "	76 mm	31.4 mm	2.99 in	1.24 in	4000 V	Universal Input	100 V	AC or DC	370 V	264 VAC	85 VAC	560 mA
CUI Inc. PSK-S5B-9		85 VAC 100 V	264 VAC 370 VDC	1	9 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Through Hole	5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	77 %	24.5 mm	0.71 in	37 mm	18 mm	1.46 in	0.96 in		Universal Input						560 mA	26-DIP Module 5 Leads	±1%	0.5 %
CUI Inc. PSK-S5B-3		85 VAC 100 V	264 VAC 370 VDC	1	3.3 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Through Hole	3.3 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	68 %	24.5 mm	0.71 in	37 mm	18 mm	1.46 in	0.96 in		Universal Input						1 A	26-DIP Module 5 Leads	±1%	0.5 %
CUI Inc. PSK-S5B-5-L	1 A	85 VAC 100 V	264 VAC 370 VDC	1	5 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	75 %	24.5 mm	0.71 in	37 mm	18 mm	1.46 in	0.96 in	4000 V	Universal Input
CUI Inc. PSK-S5B-12-DIN				1	12 V	CB Scheme EN IEC UL	ITE (Commercial)			5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	79 %	31.5 mm	1.24 "	76 mm	31.4 mm	2.99 in	1.24 in	4000 V	Universal Input	100 V	AC or DC	370 V	264 VAC	85 VAC	420 mA
CUI Inc. PSK-S5B-15-T		85 VAC 100 V	264 VAC 370 VDC	1	15 V	CB Scheme EN IEC UL	ITE (Commercial)	Enclosed	Chassis Mount	5 W	55024 55032 Class A 60950-1 61000-3-2 62368-1	79 %	31.5 mm	1.06 in	76 mm	26.8 mm	2.99 in	1.24 in	4000 V	Universal Input										330 mA
