JR16WP Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN PLUG HSG FMALE 3POS INLINE
| Part | Mounting Type | Insert Material | Contact Type | Shell Size - Insert | Shell Finish | Note | Orientation | Housing Color | Material Flammability Rating | Contact Shape | Type | Shielding | Features | Shell Material | Operating Temperature [Max] | Operating Temperature [Min] | Fastening Type | Connector Type | Contact Size | Ingress Protection | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Color | Contact Finish - Mating | Number of Positions | Backshell Material, Plating | Applications | Current Rating (Amps) | Voltage Rating | Primary Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Free Hanging (In-Line) | Polycarbonate (PC) | Crimp | 16 | Chrome | Contacts Not Included | Keyed | Black | UL94 V-0 | Circular | For Female Sockets | Unshielded | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Housing | 1.6 mm | IP67/IP68 | |||||||||||
Hirose Electric Co Ltd | |||||||||||||||||||||||||||||||
 Hirose Electric Co Ltd | Free Hanging (In-Line) | Phenol Formaldehyde (PF) | 16 | Black Chromium | Keyed | UL94 V-0 | Unshielded | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Female Sockets | IP67/IP68 | 78.7 µin | 2 µm | Copper Alloy | Black | Silver | 7 | Black Chrome Brass | Automotive Industrial Telecommunications | 10 A | 100 VAC 140 VDC | Metal | ||||||
 Hirose Electric Co Ltd | Free Hanging (In-Line) | Polycarbonate (PC) | Crimp | 16 | Chrome | Contacts Not Included | Keyed | Black | UL94 V-0 | Circular | For Female Sockets | Unshielded | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Housing | 1 mm | IP67/IP68 | 10 | ||||||||||
 Hirose Electric Co Ltd | Free Hanging (In-Line) | Phenol Formaldehyde (PF) | 16 | Black Chromium | Keyed | UL94 V-0 | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Male Pins | IP67/IP68 | 118.1 µin | 3 µm | Copper Alloy | Black | Silver | 7 | Black Chrome Brass | Automotive Industrial Telecommunications | 10 A | 100 VAC 140 VDC | Metal | |||||||
Hirose Electric Co Ltd | |||||||||||||||||||||||||||||||
 Hirose Electric Co Ltd | Free Hanging (In-Line) | Phenol Formaldehyde (PF) | 16 | Black Chromium | Keyed | UL94 V-0 | Unshielded | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Female Sockets | IP67/IP68 | 78.7 µin | 2 µm | Copper Alloy | Black | Silver | 10 | Black Chrome Brass | Automotive Industrial Telecommunications | 5 A | 100 VAC 140 VDC | Metal | ||||||
Hirose Electric Co Ltd | Free Hanging (In-Line) | Polycarbonate (PC) | Crimp | 16 | Chrome | Contacts Not Included | Keyed | Black | UL94 V-0 | Circular | For Male Pins | Unshielded | Backshell Coupling Nut | Aluminum Alloy | 85 °C | -25 °C | Threaded | Plug Housing | 1 mm | IP67/IP68 | 10 |
