AM75QB Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER 12V 75W

Part	Applications	Number of Outputs	Voltage - Input (Max) [Max]	Approval Agency	Voltage - Isolation	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Package / Case	Type	Voltage - Output 1	Supplier Device Package	Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Power (Watts)	Efficiency	Features	Standard Number	Size / Dimension [y]	Size / Dimension [z]	Current - Output (Max)
aimtec AM75QB-4812SH22-NZ	ITE (Commercial)	1	75 V	CE	2250 VDC	Through Hole	85 °C	-40 C	0.5 in	61.8 mm	2.43 in	40.2 mm	1.58 "	12.7 mm	Quarter Brick	Isolated Module	12 V	Quarter Brick	18 V	6.25 A	75 W	92 %	Remote On/Off
aimtec AM75QB-11024SA30JZ-B	Industrial Railway	1	160 V		3000 V	Through Hole	105 ░C	-40 C	0.5 in	60.8 mm	2.39 "		1.54 in		Quarter Brick	Isolated Module	24 V	Quarter Brick	43 V	3.12 A	75 W	91 %	Adjustable Output Remote On/Off Remote Sense	50155	39.2 mm	12.7 mm
aimtec AM75QB-11015SA30JZ-B	Industrial Railway	1	160 V		3000 V	Through Hole	105 ░C	-40 C	0.5 in	60.8 mm	2.39 "		1.54 in		Quarter Brick	Isolated Module	15 V	Quarter Brick	43 V		75 W	89 %	Adjustable Output Remote On/Off Remote Sense		39.2 mm	12.7 mm	5 A
aimtec AM75QB-11012SA30JZ-B	Industrial Railway	1	160 V		3000 V	Through Hole	105 ░C	-40 C	0.5 in	60.8 mm	2.39 "		1.54 in		Quarter Brick	Isolated Module	12 V	Quarter Brick	43 V	6.25 A	75 W	89 %	Adjustable Output Remote On/Off Remote Sense	50155	39.2 mm	12.7 mm
