895-062 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Termination | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Rows [custom] | Contact Material | Gender | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Color | Contact Finish | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Card Type | Termination Rows | Number of Rows | Number of Positions/Bay/Row | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 1 | 1 | 62 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 1 | 1 | 62 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | M3 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Right Angle Through Hole | Black | Gold | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 1 | 1 | 62 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Wire Wrap | Cantilever | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Board Edge Straddle Mount | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | Card Extender | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Right Angle Through Hole | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 62 | Solder Eyelet(s) | Cantilever | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 0.25 Ám | 10 Áin | Single | Non Specified - Single Edge | 1 | 1 | 62 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Wire Wrap | Cantilever | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | 62 | Solder | Cantilever | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 2 | Copper Alloy | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Through Hole | Black | Gold | 31 | 0.25 Ám | 10 Áin | Dual | Non Specified - Dual Edge |
