GRN-200 Series

Catalog

GRN-200-4002 CH

Part	Voltage - Output 3	Standard Number	Number of Outputs	Current - Output 2	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output 1	Features	Voltage - Output 1	Power (Watts)	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Efficiency	Approval Agency	Type	Voltage - Output 2	Applications	Voltage - Output 4	Current - Output 3	Current - Output 4
Integrated Power Designs 1011435CH	12 V	60601-1; 62368-1	4	8 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	3.3 V	ITE (Commercial) Medical	-12 V	2 A	2 A
Integrated Power Designs 1011437CH	15 V	60601-1; 62368-1	4	3 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	24 V	ITE (Commercial) Medical	-15 V	2 A	2 A
Integrated Power Designs 1011501CH	-24 V	60601-1; 62368-1	3	1.5 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	24 V	ITE (Commercial) Medical		1.5 A
Integrated Power Designs 1011442CH		60601-1; 62368-1	2	6 A	Chassis Mount	70 °C	-20 °C	12 A	Adjustable Output Remote Sense Universal Input	12 V	216 W	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	-12 V	ITE (Commercial) Medical
Integrated Power Designs 1011441CH		60601-1; 62368-1	2	6 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	222 W	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	12 V	ITE (Commercial) Medical
Integrated Power Designs 1011442CHCO		60601-1; 62368-1	2	6 A	Chassis Mount	70 °C	-20 °C	12 A	Adjustable Output Remote Sense Universal Input	12 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Enclosed	-12 V	ITE (Commercial) Medical
Integrated Power Designs 1011435CHCO	12 V	60601-1; 62368-1	4	8 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Enclosed	3.3 V	ITE (Commercial) Medical	-12 V	2 A	2 A
Integrated Power Designs 1011440CHCO		60601-1; 62368-1	2	3 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Enclosed	25 V	ITE (Commercial) Medical
Integrated Power Designs 1011439CH	-15 V	60601-1; 62368-1	3	5 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3 "	76.2 mm	30 mm	1.18 in	127 mm	5 "	89 %	CE cURus TUV UKCA	Chassis	15 V	ITE (Commercial) Medical		2 A
Integrated Power Designs 1011438CHCO	-12 V	60601-1; 62368-1	3	6 A	Chassis Mount	70 °C	-20 °C	30 A	Adjustable Output Remote Sense Universal Input	5 V	200 Watts	3.14 in	79.9 mm	41.9 mm	1.65 "	127 mm	5 "	89 %	CE cURus TUV UKCA	Enclosed	12 V	ITE (Commercial) Medical		2 A
