846-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 29POS 0.125
| Part | Material - Insulation | Termination Rows | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Flange Feature | Read Out | Card Type | Contact Type | Number of Positions | Contact Material | Number of Rows | Termination | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Gender | Contact Finish | Color | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Flush Mount M3 Threaded Insert Top Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Floating Bobbin Top Mount Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Gold | Green | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Female | Gold | Green | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 0.25 Ám | 10 Áin | 29 | 125 °C | -40 C | 3.18 mm | 0.125 in | Floating Bobbin Flush Mount | Single | Non Specified - Single Edge | Cantilever | 29 | Copper Alloy | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Female | Gold | Green | 0.116 " | 2.95 mm |
