PDTB143EQA Series

50 V, 500 mA PNP resistor-equipped transistors

Manufacturer: Freescale Semiconductor - NXP

Catalog

50 V, 500 mA PNP resistor-equipped transistors

Part	Frequency - Transition	Resistor - Emitter Base (R2)	Voltage - Collector Emitter Breakdown (Max) [Max]	Grade	Supplier Device Package	Vce Saturation (Max) @ Ib, Ic	Mounting Type	Transistor Type	Resistor - Base (R1)	Power - Max [Max]	Package / Case	Current - Collector (Ic) (Max) [Max]	Current - Collector Cutoff (Max) [Max]	Qualification	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]
Freescale Semiconductor - NXP PDTB143ETR	140 MHz	4700 Ohms	50 V	Automotive	TO-236AB	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms	320 mW	SC-59 SOT-23-3 TO-236-3	500 mA	500 nA	AEC-Q100	60
Freescale Semiconductor - NXP PDTB143XTVL	140 MHz	10 kOhms	50 V	Automotive	TO-236AB	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms	320 mW	SC-59 SOT-23-3 TO-236-3	500 mA	500 nA	AEC-Q100	70
Freescale Semiconductor - NXP PDTB143ETVL	140 MHz	4700 Ohms	50 V	Automotive	TO-236AB	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms	320 mW	SC-59 SOT-23-3 TO-236-3	500 mA	500 nA	AEC-Q100	60
Freescale Semiconductor - NXP PDTB143EUF	140 MHz	4700 Ohms	50 V	Automotive	SOT-323	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms		SC-70 SOT-323	500 mA	500 nA	AEC-Q100	60
Freescale Semiconductor - NXP PDTB143XUX	140 MHz	10 kOhms	50 V	Automotive	SOT-323	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms		SC-70 SOT-323	500 mA	500 nA	AEC-Q100	70
Freescale Semiconductor - NXP PDTB143EQAZ	150 MHz	4700 Ohms	50 V	Automotive	DFN1010D-3	100 mV	Surface Mount	PNP - Pre-Biased	4.7 kOhms	325 mW	3-XDFN Exposed Pad	500 mA	500 nA	AEC-Q101	60

Catalog

50 V, 500 mA PNP resistor-equipped transistors

Description

PNP Resistor-Equipped Transistor (RET) family in a leadless ultra small DFN1010D-3 (SOT1215) Surface-Mounted Device (SMD) plastic package with visible and solderable side pads.
