A3-14PA Series

Catalog

CONN HEADER SMD 14POS 2MM

Part	Mated Stacking Heights [z]	Contact Finish Thickness - Post	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Style	Connector Type	Number of Positions	Insulation Material	Contact Finish - Post	Contact Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Row Spacing - Mating	Row Spacing - Mating	Fastening Type	Material Flammability Rating	Contact Shape	Voltage Rating	Pitch - Mating	Pitch - Mating	Number of Rows [custom]	Insulation Color	Shrouding	Contact Length - Mating	Contact Length - Mating	Contact Material	Mounting Type	Insulation Height	Insulation Height
Hirose Electric Co Ltd A3-14PA-2SV(71)	6 mm 8.8 mm	Flash	Solder	-55 C	85 °C	Gold	Board to Board Cable	Header	14	Polyphenylene Sulfide (PPS)	Gold	Male Pin	8 µin	0.203 µm	All	2 mm	0.079 in	Push-Pull	UL94 V-0	Square	200 V	0.079 "	2 mm	2	Brown	Unshrouded	3.5 mm	0.138 in	Brass	Surface Mount	1.8 mm	0.071 in
Hirose Electric Co Ltd A3-14PA-2SV	6 mm 8.8 mm		Solder	-55 C	85 °C	Gold	Board to Board Cable	Header	14	Polyphenylene Sulfide (PPS)		Male Pin			All	2 mm	0.079 in	Push-Pull	UL94 V-0	Square	200 V	0.079 "	2 mm	2	Brown	Unshrouded	3.5 mm	0.138 in	Brass	Surface Mount	1.8 mm	0.071 in
