896-016 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 16POS 0.125
| Part | Termination Rows | Material - Insulation | Card Type | Pitch | Pitch | Contact Material | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Read Out | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Termination | Contact Finish | Color | Number of Positions | Contact Type | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows [custom] | Number of Rows [custom] | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.18 mm | 0.125 in | Copper Alloy | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.25 Ám | 10 Áin | Solder | Gold | Black | 16 | Cantilever | Through Hole | 0.156 " | 3.96 mm | Female | 125 °C | -40 C | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Gold | Black | 16 | Cantilever | Board Edge Straddle Mount | Female | 125 °C | -40 C | 2 | 2 | 4-40 Threaded Insert Top Mount Opening | Card Extender | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.18 mm | 0.125 in | Copper Alloy | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.25 Ám | 10 Áin | Solder | Gold | Black | 16 | Cantilever | Right Angle Through Hole | Female | 125 °C | -40 C | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.18 mm | 0.125 in | Copper Alloy | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.25 Ám | 10 Áin | Solder | Gold | Black | 16 | Cantilever | Right Angle Through Hole | 0.116 " | 2.95 mm | Female | 125 °C | -40 C | Floating Bobbin Flush Mount | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Wire Wrap | Gold | Black | 16 | Cantilever | Through Hole | Female | 125 °C | -40 C | 2 | 2 | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 3.18 mm | 0.125 in | Copper Alloy | 16 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 0.25 Ám | 10 Áin | Wire Wrap | Gold | Black | 16 | Cantilever | Through Hole | Female | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Gold | Black | 16 | Cantilever | Through Hole | 0.116 " | 2.95 mm | Female | 125 °C | -40 C | 2 | 2 | Floating Bobbin Top Mount Opening | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Solder | Gold | Black | 16 | Cantilever | Right Angle Through Hole | Female | 125 °C | -40 C | 2 | 2 | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Wire Wrap | Gold | Black | 16 | Cantilever | Through Hole | Female | 125 °C | -40 C | 2 | 2 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 8 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Gold | Black | 16 | Cantilever | Board Edge Straddle Mount | 0.128 " | 3.25 mm | Female | 125 °C | -40 C | 2 | 2 | Flush Mount Top Opening Unthreaded | Card Extender |
