TEP 200 Series
Manufacturer: Traco Power
Beta
⌘K
DC/DC CONVERTER 28V 238W
| Part | Power (Watts) | Type | Voltage - Input (Max) [Max] | Applications | Efficiency | Number of Outputs | Current - Output (Max) [Max] | Voltage - Output 1 | Voltage - Isolation | Voltage - Input (Min) [Min] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Approval Agency | Supplier Device Package | Package / Case | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Traco Power | 238 W | Open Frame | 160 V | ITE (Commercial) Railway | 90 % | 1 | 8.5 A | 28 V | 3000 V | 43 V | 2.4 in | 1.53 in | 38.9 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus | |||
 Traco Power | 180 W | Enclosed | 36 V | ITE (Commercial) Railway | 90 % | 1 | 36 A | 5 V | 3000 V | 9 V | 2.4 in | 1.33 in | 33.8 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus | |||
 Traco Power | 180 W | Open Frame | 36 V | ITE (Commercial) Railway | 89 % | 1 | 15 A | 12 V | 3000 V | 9 V | 2.4 in | 1.53 in | 38.9 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus | |||
 Traco Power | 180 W | Isolated Module | 36 V | ITE (Commercial) Railway | 90 % | 1 | 12 A | 15 V | 2250 VDC | 9 V | 2.28 in | 0.5 in | 12.7 mm | 61 mm | 57.9 mm | 2.4 in | -40 C | 75 ░C | Through Hole | Half Brick | Half Brick | OTP OVP Remote On/Off SCP UVLO | |
Traco Power | 210 W | Isolated Module | 75 V | ITE (Commercial) Railway | 91 % | 1 | 14 A | 15 V | 2250 VDC | 18 V | 2.28 in | 0.5 in | 12.7 mm | 61 mm | 57.9 mm | 2.4 in | -40 C | 75 ░C | Through Hole | Half Brick | Half Brick | OTP OVP Remote On/Off SCP UVLO | |
 Traco Power | 180 W | Open Frame | 36 V | ITE (Commercial) Railway | 90 % | 1 | 7.5 A | 24 V | 3000 V | 9 V | 2.4 in | 1.53 in | 38.9 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus | |||
Traco Power | 216 W | Isolated Module | 75 V | ITE (Commercial) Railway | 90 % | 1 | 4.5 A | 48 V | 2250 VDC | 18 V | 2.28 in | 0.5 in | 12.7 mm | 61 mm | 57.9 mm | 2.4 in | -40 C | 75 ░C | Through Hole | Half Brick | Half Brick | OTP OVP Remote On/Off SCP UVLO | |
 Traco Power | 210 W | Enclosed | 75 V | ITE (Commercial) Railway | 91 % | 1 | 7.5 A | 28 V | 3000 V | 18 V | 2.4 in | 1.33 in | 33.8 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus | |||
Traco Power | 210 W | Open Frame | 75 V | ITE (Commercial) Railway | 91 % | 1 | 7.5 A | 28 V | 3000 V | 18 V | 2.4 in | 1.53 in | 38.9 mm | 85.1 mm | 61 mm | 3.35 in | -40 C | 75 ░C | Chassis Mount | CB CE cURus |
