ISP844 Series

Catalog

OPTOCOUPLER, TRANSISTOR OUTPUT, 4 CHANNEL, DIP, 16 PINS, 50 MA, 5.3 KV, 20 %

Part	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Voltage - Isolation [custom]	Vce Saturation (Max) [Max]	Mounting Type	Current Transfer Ratio (Max)	Output Type	Voltage - Output (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current - DC Forward (If) (Max) [Max]	Current - Output / Channel [custom]	Current Transfer Ratio (Min) [Min]	Package / Case [x]	Package / Case	Package / Case [x]	Number of Channels [custom]
Isocom Components 2004 LTD ISP844X	4 µs	3 µs	5300 Vrms	200 mV	Through Hole	300 %	Transistor	35 V	-30 ░C	100 °C	50 mA	50 mA	20 %	0.3 in	16-DIP	7.62 mm	4
