DF1-9 Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN SOCKET 9POS IDC 28AWG TIN
| Part | Contact Type | Features | Number of Rows | Mounting Type | Wire Gauge | Color | Cable Termination | Wire Type | Number of Positions | Contact Finish | Connector Type | Pitch | Pitch | Fastening Type | Contact Finish - Post | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Insulation Material | Contact Shape | Pitch - Mating | Pitch - Mating | Insulation Color | Insulation Height [z] | Insulation Height [z] | Style | Contact Material | Voltage Rating | Contact Length - Mating | Contact Length - Mating | Contact Length - Post | Contact Length - Post | Number of Positions Loaded | Operating Temperature [Max] | Operating Temperature [Min] | Material Flammability Rating | Termination | Current Rating (Amps) | Shrouding | Overall Contact Length | Overall Contact Length | For Use With/Related Products | Features | Accessory Type | Features [Max] | Features [Min] | Insulation Height [custom] | Insulation Height [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Female Socket | Feed Through | 1 | Free Hanging (In-Line) | 28 AWG | Brown | IDC | Discrete | 9 | Tin | Socket | 2.5 mm | 0.098 in | ||||||||||||||||||||||||||||||||||
Hirose Electric Co Ltd | Female Socket | Feed Through | 1 | Free Hanging (In-Line) | 26 AWG | Brown | IDC | Discrete | 9 | Tin | Socket | 2.5 mm | 0.098 in | ||||||||||||||||||||||||||||||||||
Hirose Electric Co Ltd | Male Pin | 1 | Through Hole | 9 | Header | Friction Lock | Tin | 39.4 µin | 1 µm | Nylon Polyamide (PA) | Square | 2.5 mm | 0.098 in | Brown | 7.5 mm | 0.295 in | Board to Cable/Wire | Brass | 250 V | 0.177 in | 4.5 mm | 0.118 in | 3 mm | All | 85 °C | -30 ░C | UL94 V-0 | Solder | 3 A | Shrouded - 1 Wall | 10 mm | 0.394 in | |||||||||||||||
Hirose Electric Co Ltd | 9 | DF1 Series | 24 AWG | Cap (Cover) | |||||||||||||||||||||||||||||||||||||||||||
Hirose Electric Co Ltd | 9 | DF1 Series | Cap (Cover) | 28 AWG | 26 AWG | ||||||||||||||||||||||||||||||||||||||||||
 Hirose Electric Co Ltd | Female Socket | Feed Through | 1 | Free Hanging (In-Line) | 24 AWG | Brown | IDC | Discrete | 9 | Tin | Socket | 2.5 mm | 0.098 in | ||||||||||||||||||||||||||||||||||
Hirose Electric Co Ltd | Male Pin | 1 | Right Angle Through Hole | 9 | Header | Friction Lock | Tin | 39.4 µin | 1 µm | Nylon Polyamide (PA) | Square | 2.5 mm | 0.098 in | Brown | Board to Cable/Wire | Brass | 250 V | 0.177 in | 4.5 mm | 0.118 in | 3 mm | All | 85 °C | -30 ░C | UL94 V-0 | Solder | 3 A | Shrouded - 1 Wall | 0.236 " | 6 mm |
