PIC18LF24J11 Series
Manufacturer: Microchip Technology
Catalog
Key Features
• * 13nA Deep Sleep mode (Watch Webinar)
• * 54nA Sleep mode (RAM retention)
• * 830nA Real Time Clock & Calendar operation in Sleep modes
• * 820nA Watch Dog Timer operation in Sleep modes
• * Deep Sleep mode ideal for battery applications
• * Peripheral Pin Select for mapping digital peripherals to various I/O for design
• flexibility
• * Hardware RTCC provides clock, calendar & alarm functions
• * Charge Time Measurement Unit (CTMU) supports capacitive touch screens
• * 2 Enhanced Capture / Compare / PWM modules
• * 2 MSSP serial ports for SPI with DMA or I2C™ communication
• * 2 Enhanced USART modules
• * Dual analog comparators
• * 10 ch, 10-bit ADC
• * Self programming Flash supports 10k erase/write cycles & 20 years retention
• * Operating voltage 2.0 - 3.6V, 5.5V tolerant digital inputs
Description
AI
This family provides low power and high performance 8-bit MCU with peripheral flexibility in a small package for cost sensitive applications in the PIC18 J-series. New features include Deep sleep mode for low power applications, Peripheral Pin Select for design flexibility for mapping peripherals to I/O pins and a CTMU module for easy capacitive touch user interfaces. The PIC18F46J11 family is ideal for applications requiring cost-effective, low-power solutions with a robust peripheral set in a small package.
