395 Series
Manufacturer: EDAC Inc.
Catalog
STANDARD CARD EDGE CONNECTORS .100" (2.54MM) PITCH CARD EDGE CONNECTOR
...
| Part | Termination Rows [custom] | Material - Insulation | Read Out | Card Type | Flange Feature | Contact Finish | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Color | Number of Positions/Bay/Row | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Mounting Type | Features | Contact Type | Gender | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 35 | Solder | -40 C | 105 ░C | 70 | Right Angle Through Hole | Card Guides | Cantilever | Female | ||||||
 EDAC Inc. | Polyester Thermoplastic | Single | Non Specified - Single Edge | Floating Bobbin Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Black | 14 | Wire Wrap | -40 C | 105 ░C | 14 | Through Hole | Cantilever | Female | 1 | 1 | 0.116 " | 2.95 mm | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 42 | Solder | -40 C | 105 ░C | Right Angle Through Hole | Card Guides | Cantilever | Female | 84 | ||||||
 EDAC Inc. | Dual | Non Specified - Dual Edge | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 43 | Wire Wrap | -40 C | 105 ░C | 86 | Through Hole | Cantilever | Female | 0.128 " | 3.25 mm | ||||||||
 EDAC Inc. | Dual | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 43 | Solder | -40 C | 105 ░C | 86 | Board Edge Straddle Mount | Card Extender Card Guides | Cantilever | Female | ||||||||
 EDAC Inc. | Polyester Thermoplastic | Single | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Black | Wire Wrap | -40 C | 105 ░C | 21 | Through Hole | Card Guides | Cantilever | Female | 1 | 1 | 21 | ||||||
 EDAC Inc. | Dual | Non Specified - Dual Edge | Side Mount Opening Unthreaded | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | Wire Wrap | -40 C | 105 ░C | 80 | Through Hole | Cantilever | Female | 0.128 " | 3.25 mm | 40 | |||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 30 | Solder | -40 C | 105 ░C | 60 | Right Angle Through Hole | Cantilever | Female | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Side Mount Opening Unthreaded | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 49 | Wire Wrap | -40 C | 105 ░C | 98 | Through Hole | Cantilever | Female | 0.128 " | 3.25 mm | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Non Specified - Dual Edge | Floating Bobbin Top Mount Opening | Gold | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | 2 | Black | 16 | Solder | -40 C | 105 ░C | Board Edge Straddle Mount | Card Extender | Cantilever | Female | 0.116 " | 2.95 mm |
