SBSMP Series
Manufacturer: Knowles Syfer
Beta
⌘K
SURFACE MOUNT C AND PI FILTER
| Part | Temperature Coefficient | Height (Max) [z] | Height (Max) [z] | Current | Package / Case | Insertion Loss | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Rated | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Capacitance | Tolerance | Mounting Type | Type | Height [z] | Height [z] | Technology | Applications | Values | Filter Order | ESD Protection | Number of Channels [custom] | Attenuation Value | Height | Package / Case | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Knowles Syfer | X7R | 0.133 in | 3.38 mm | 10 A | 2220 (5750 Metric) 3 PC Pad | 44 dB | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | 6800 pF | 20 % | Surface Mount | |||||||||||||||
 Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 1000 pF | 3rd | 1 | |||||||||||||
Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 10000 pF | 3rd | 1 | 44 dB | ||||||||||||
 Knowles Syfer | 10 A | 2220 (5750 Metric) 3 PC Pad | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.13 " | LC | General Purpose | 4700 pF | 3rd | 1 | 44 dB | 3.3 mm | ||||||||||||||
Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 0.068 µF | 3rd | 1 | 44 dB | ||||||||||||
Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 100 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 0.33 µF | 3rd | 1 | 44 dB | ||||||||||||
Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 1500 pF | 3rd | 1 | 39 dB | ||||||||||||
Knowles Syfer | X7R | 0.133 in | 3.38 mm | 10 A | 2220 (5750 Metric) 3 PC Pad | 38 dB | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | 2200 pF | 20 % | Surface Mount | |||||||||||||||
Knowles Syfer | 20 A | 2220 (5750 Metric) 3 PC Pad | -55 C | 125 °C | 500 V | 5.7 mm | 0.224 " | 0.197 " | 5 mm | Surface Mount | Low Pass | 0.133 in | 3.38 mm | LC | General Purpose | 0.068 µF | 3rd | 1 | 44 dB | ||||||||||||
 Knowles Syfer | X7R | 0.133 in | 3.38 mm | 20 A | 2220 | 44 dB | -55 C | 125 °C | 50 VDC | 5.7 mm | 0.224 " | 0.197 " | 0.47 µF | 20 % | Surface Mount | 5750 Metric | 0.133 " | 3.38 mm | 5 mm |
