1010757 Series
Manufacturer: Integrated Power Designs
Beta
⌘K
DC/DC CONVERTER 5V 24V 185W
| Part | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Input (Min) [Min] | Approval Agency | Applications | Voltage - Output 2 | Type | Mounting Type | Power (Watts) | Efficiency | Number of Outputs | Standard Number | Current - Output (Max) | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Integrated Power Designs | 36 V | 70 °C | 0 °C | 4.36 in | 183.6 mm | 44.2 mm | 1.74 " | 110.7 mm | 7.23 in | 18 V | CE cURus TUV UKCA | ITE (Commercial) Medical | 24 V | Enclosed | Chassis Mount | 185 W | 84 % | 2 | 60601-1; 62368-1 | 4 A 20 A | 5 V |
 Integrated Power Designs | 36 V | 70 °C | 0 °C | 4.36 in | 183.6 mm | 44.2 mm | 1.74 " | 110.7 mm | 7.23 in | 18 V | CE cURus TUV UKCA | ITE (Commercial) Medical | 24 V | Chassis | Chassis Mount | 185 W | 84 % | 2 | 60601-1; 62368-1 | 4 A 20 A | 5 V |
