STTH1R02-Y Series

Automotive 200 V, 1 A SOD123Flat Ultrafast Diode

Catalog

Automotive 200 V, 1 A SOD123Flat Ultrafast Diode

Part	Operating Temperature - Junction [Min]	Operating Temperature - Junction [Max]	Qualification	Mounting Type	Voltage - DC Reverse (Vr) (Max) [Max]	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Supplier Device Package	Package / Case	Grade	Technology	Current - Average Rectified (Io)	Speed	Voltage - Forward (Vf) (Max) @ If [Max]
STMicroelectronics STTH1R02ZFY	-40 °C	175 ░C	AEC-Q101	Surface Mount	200 V	32 ns	500 nA	SOD-123F	SOD-123F	Automotive	Standard	1 A	200 mA 500 ns	1 V

Catalog

Automotive 200 V, 1 A SOD123Flat Ultrafast Diode

Description

The STTH1R02-Y is an ultrafast recovery rectifier used for energy recovery in automotive applications, housed in a SOD123Flat package for improved space saving. It is especially designed for reverse battery protection function in all automotive application. The compromise between forward voltage drop and recovery time offers optimized performances.
