220205 Series
2.00mm Pitch, Micro-Lock Plus PCB Header, Dual Row, Right Angle, Surface Mount, Matte Tin Plating, 10 Circuits, Low-Halogen, Natural (White)
Manufacturer: Molex
Catalog
2.00mm Pitch, Micro-Lock Plus PCB Header, Dual Row, Right Angle, Surface Mount, Matte Tin Plating, 10 Circuits, Low-Halogen, Natural (White)
| Part | Style | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Color | Number of Positions Loaded | Current Rating (Amps) | Shrouding | Features | Contact Finish - Post | Fastening Type | Termination | Pitch - Mating | Pitch - Mating | Number of Positions | Number of Rows [custom] | Connector Type | Insulation Height [z] | Insulation Height | Contact Material | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Contact Type | Insulation Material | Mounting Type | Contact Shape | Voltage Rating | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 8 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
 Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 20 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 14 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 10 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 12 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 18 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
 Molex | Board to Cable/Wire | -40 C | 105 ░C | Black | All | 2.8 A | Shrouded - 4 Wall | Solder Retention | Tin | Push-Pull | Solder | 0.079 " | 2 mm | 26 | 2 | Header | 0.445 " | 11.3 mm | Brass | 39.4 µin | 1 µm | Male Pin | Nylon Polyamide (PA) | Right Angle Surface Mount | Rectangular | 250 VAC | UL94 V-0 |
