UPT Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 420VOLTS 68UF 18X31.5 20%

Part	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [z]	Polarization	Lifetime @ Temp.	Lead Spacing	Lead Spacing	Capacitance	Ripple Current @ High Frequency	Package / Case	Tolerance	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ Low Frequency	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max)	Height - Seated (Max) [Max]
Nichicon UPTW6680MHD6	General Purpose	105 ░C	-25 °C	420 V	1.299 in	33 mm	Polar	5000 Hrs	0.295 in	7.5 mm	68 µF	816 mA	Can Radial	20 %	0.709 in	18 mm	510 mA	Through Hole
Nichicon UPT2P391MRD	General Purpose	105 ░C	-25 °C	220 V	42 mm			5000 Hrs	0.394 in	10 mm	390 µF	1.84 A	Can Radial	20 %	0.866 "	22 mm	1.15 A	Through Hole	1.654 in
Nichicon UPTW6680MHD	General Purpose	105 ░C	-25 °C	420 V			Polar	5000 Hrs	0.295 in	7.5 mm	68 µF	816 mA	Can Radial	20 %	0.63 in	16 mm	510 mA	Through Hole	1.457 in	37 mm
Nichicon UPT2E151MHD	General Purpose	105 ░C	-25 °C	250 V	1.299 in	33 mm		5000 Hrs	0.295 in	7.5 mm	150 µF	992 mA	Can Radial	20 %	0.63 in	16 mm	620 mA	Through Hole
Nichicon UPT2E470MPD	General Purpose	105 ░C	-25 °C	250 V	1.299 in	33 mm		5000 Hrs	0.197 "	5 mm	47 µF	432 mA	Can Radial	20 %	0.394 in	10 mm	270 mA	Through Hole
Nichicon UPT2P271MHD	General Purpose	105 ░C	-25 °C	220 V			Polar	5000 Hrs	0.295 in	7.5 mm	270 µF	1.408 A	Can Radial	20 %	0.63 in	16 mm	880 mA	Through Hole		41.5 mm	1.634 in
Nichicon UPT2P221MHD6	General Purpose	105 ░C	-25 °C	220 V	1.299 in	33 mm		5000 Hrs	0.295 in	7.5 mm	220 µF	1.232 A	Can Radial	20 %	0.709 in	18 mm	770 mA	Through Hole
Nichicon UPT2W680MHD	General Purpose	105 ░C	-25 °C	450 V				5000 Hrs	0.295 in	7.5 mm	68 µF	784 mA	Can Radial	20 %	0.63 in	16 mm	490 mA	Through Hole		41.5 mm	1.634 in
