2SA1962 Series

PNP Epitaxial Silicon Transistor

Catalog

PNP Epitaxial Silicon Transistor

Part	Power - Max [Max]	Transistor Type	Operating Temperature [Min]	Operating Temperature [Max]	Current - Collector Cutoff (Max) [Max]	Current - Collector (Ic) (Max) [Max]	Vce Saturation (Max) @ Ib, Ic	Package / Case	Voltage - Collector Emitter Breakdown (Max)	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Supplier Device Package	Mounting Type	Frequency - Transition
ON Semiconductor 2SA1962RTU	130 W	PNP	-55 °C	150 °C	5 µA	17 A	3 V	SC-65-3 TO-3P-3	250 V	55	TO-3P	Through Hole	30 MHz

PNP Epitaxial Silicon Transistor

• High Current Capability: IC = -15A

• High Power Dissipation : 130watts

• High Fequency : 30MHz

• High Voltage : VCEO= -250V

• Wide S.O.A for reliable operation

• Excellent Gain Linearity for low THD

• Complement to 2SC5242/FJA4313

• Thermal and electrical Spice models are available

• High-Fidelity Audio Output Amplifier

• General Purpose Power Amplifier
