PMV50 Series
Manufacturer: Freescale Semiconductor - NXP
Beta
⌘K
P-CHANNEL MOSFET
| Part | Vgs(th) (Max) @ Id | FET Type | Input Capacitance (Ciss) (Max) @ Vds [Max] | Power Dissipation (Max) | Supplier Device Package | Technology | Drive Voltage (Max Rds On, Min Rds On) | Current - Continuous Drain (Id) @ 25°C | Drain to Source Voltage (Vdss) | Operating Temperature [Min] | Operating Temperature [Max] | Rds On (Max) @ Id, Vgs | Gate Charge (Qg) (Max) @ Vgs [Max] | Vgs (Max) | Package / Case | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Freescale Semiconductor - NXP | 900 mV | P-Channel | 744 pF | 4.63 W 490 mW | TO-236AB | MOSFET (Metal Oxide) | 1.5 V 4.5 V | 3.6 A | 20 V | -55 °C | 150 °C | 60 mOhm | 12 nC | 12 V | SC-59 SOT-23-3 TO-236-3 | Surface Mount |
