IKW40N120 Series

Manufacturer: INFINEON

Catalog

HE IKW40N120CS7 IS A 1200 V, 40 A IGBT7 S7 WITH ANTI-PARALLEL DIODE IN TO-247 PACKAGE

Part	Reverse Recovery Time (trr)	Voltage - Collector Emitter Breakdown (Max) [Max]	Switching Energy	Current - Collector (Ic) (Max) [Max]	Vce(on) (Max) @ Vge, Ic	Td (on/off) @ 25°C	Td (on/off) @ 25°C	Operating Temperature [Max]	Operating Temperature [Min]	Gate Charge	Test Condition	Mounting Type	Power - Max [Max]	Current - Collector Pulsed (Icm)	Package / Case	IGBT Type	Supplier Device Package	Td (on/off) @ 25°C [custom]	Td (on/off) @ 25°C [custom]	Td (on/off) @ 25°C
INFINEON IKW40N120CS7XKSA1	175 ns	1200 V	1.75 mJ 2.55 mJ	82 A	2 V	190 ns	27 ns	175 °C	-40 °C	230 nC	4 Ohm 15 V 40 A 600 V	Through Hole	357 W	120 A	TO-247-3	Trench Field Stop	PG-TO247-3
INFINEON IKW40N120CS6XKSA1	400 ns	1200 V	1.55 mJ 2.55 mJ	80 A	2.15 V			175 °C	-40 °C	285 nC	9 Ohm 15 V 40 A 600 V	Through Hole	500 W		TO-247-3	Trench Field Stop	PG-TO247-3-41	315 ns	27 ns
INFINEON IKW40N120T2FKSA1	258 ns	1200 V	5.25 mJ	75 A	2.2 V			175 °C	-40 °C	192 nC	12 Ohm 15 V 40 A 600 V	Through Hole	480 W		TO-247-3	Trench	PG-TO247-3-1			33 ns 314 ns
