BT134 Series

Catalog

TRIAC SENS GATE 600V 1A SC73

Part	Package / Case	Voltage - Off State	Current - Non Rep. Surge 50, 60Hz (Itsm)	Configuration	Current - Gate Trigger (Igt) (Max) [Max]	Supplier Device Package	Triac Type	Mounting Type	Voltage - Gate Trigger (Vgt) (Max)	Operating Temperature	Current - Hold (Ih) (Max) [Max]	Current - On State (It (RMS)) (Max) [Max]	Current - On State (It (RMS)) (Max)	Operating Temperature [Min]	Operating Temperature [Max]
WeEn Semiconductors BT134W-600E,115	TO-261-4 TO-261AA	600 V	10 A 11 A	Single	10 mA	SC-73	Logic - Sensitive Gate	Surface Mount	1.5 V	125 ¯C	15 mA
WeEn Semiconductors BT134-600E,127	SOT-82	600 V	25 A 27 A	Single	10 mA	SOT-82-3	Logic - Sensitive Gate	Through Hole	1.5 V	125 ¯C	15 mA	4 A
WeEn Semiconductors BT134-800,127	SOT-82	800 V	25 A 27 A	Single	35 mA	SOT-82-3	Standard	Through Hole	1.5 V	125 ¯C	15 mA	4 A
WeEn Semiconductors BT134-600,127	SOT-82	600 V	25 A 27 A	Single	35 mA	SOT-82-3	Standard	Through Hole	1.5 V	125 ¯C	15 mA	4 A
WeEn Semiconductors BT134W-600D,115	TO-261-4 TO-261AA	600 V	10 A 11 A	Single	5 mA	SC-73	Logic - Sensitive Gate	Surface Mount	1.5 V	125 ¯C	10 mA
WeEn Semiconductors BT134W-600,115	TO-261-4 TO-261AA	600 V	10 A 11 A	Single	35 mA	SC-73	Standard	Surface Mount	1.5 V	125 ¯C	15 mA
WeEn Semiconductors BT134W-800,115	TO-261-4 TO-261AA	800 V	10 A 11 A	Single	35 mA	SC-73	Standard	Surface Mount	1.5 V	125 ¯C	15 mA
WeEn Semiconductors BT134W-600,135	TO-261-4 TO-261AA	600 V	10 A 11 A	Single	35 mA	SC-73	Standard	Surface Mount	1.5 V	125 ¯C	15 mA
WeEn Semiconductors BT134W-800EF	TO-261-4 TO-261AA	800 V	25 A 27.5 A	Single	10 mA	SC-73	Alternistor - Snubberless	Surface Mount	1 V		8 mA		2 A	-40 C	125 °C
WeEn Semiconductors BT134-600D,127	SOT-82	600 V	25 A 27 A	Single	5 mA	SOT-82-3	Logic - Sensitive Gate	Through Hole	1.5 V	125 ¯C	10 mA	4 A
