IPC100 Series

Manufacturer: INFINEON

Catalog

INFINEON’S IPC100N04S5-1R2 MOSFET FOR EFFICIENT POWER MANAGEMENT, HIGH PERFORMANCE, AND RELIABILITY. FIND DATA SHEET, PARAMETERS AND ORDERING INFORMATION.

Part	Grade	FET Type	Input Capacitance (Ciss) (Max) @ Vds [Max]	Gate Charge (Qg) (Max) @ Vgs	Operating Temperature [Max]	Operating Temperature [Min]	Drive Voltage (Max Rds On, Min Rds On)	Supplier Device Package	Rds On (Max) @ Id, Vgs	Vgs(th) (Max) @ Id	Vgs (Max)	Qualification	Power Dissipation (Max)	Drain to Source Voltage (Vdss)	Current - Continuous Drain (Id) @ 25°C	Package / Case	Technology	Mounting Type	Gate Charge (Qg) (Max) @ Vgs [Max]	Input Capacitance (Ciss) (Max) @ Vds
INFINEON IPC100N04S51R2ATMA1	Automotive	N-Channel	7650 pF	131 nC	175 °C	-55 °C	7 V 10 V	PG-TDSON-8-34	1.2 mOhm	3.4 V	20 V	AEC-Q101	150 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount
INFINEON IPC100N04S5L1R5ATMA1	Automotive	N-Channel	5340 pF	95 nC	175 °C	-55 °C	4.5 V 10 V	PG-TDSON-8-34	1.5 mOhm	2 V	16 V	AEC-Q101	115 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount
INFINEON IPC100N04S5L1R1ATMA1	Automotive	N-Channel	8250 pF		175 °C	-55 °C	4.5 V 10 V	PG-TDSON-8-34	1.1 mOhm	2 V	16 V	AEC-Q101	150 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount	140 nC
INFINEON IPC100N04S5L2R6ATMA1	Automotive	N-Channel			175 °C	-55 °C	4.5 V 10 V	PG-TDSON-8-34	2.6 mOhm	2 V	16 V	AEC-Q101	75 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount	55 nC	2925 pF
INFINEON IPC100N04S5L1R9ATMA1	Automotive	N-Channel	4310 pF	81 nC	175 °C	-55 °C	4.5 V 10 V	PG-TDSON-8-34	1.9 mOhm	2 V	16 V	AEC-Q101	100 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount
INFINEON IPC100N04S52R8ATMA1	Automotive	N-Channel	2600 pF	45 nC	175 °C	-55 °C	7 V 10 V	PG-TDSON-8-34	2.8 mOhm	3.4 V	20 V	AEC-Q101	75 W	40 V	100 A	8-PowerTDFN	MOSFET (Metal Oxide)	Surface Mount
