CYT3DLA Series

Manufacturer: INFINEON

Catalog

TRAVEO-2 CLUST.2.5DGRAPH

Part	EEPROM Size	Program Memory Size	Program Memory Type	Oscillator Type	Peripherals	Connectivity	Core Processor	Number of I/O	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Core Size	Core Size	Package / Case	RAM Size	Data Converters	Supplier Device Package	Speed	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type
INFINEON CYT3DLABEBQ1AESGST	128 K	4.06 MB	FLASH	External Internal	DMA I2S LVD Temp Sensor WDT	CANbus Ethernet I2C LINbus SPI UART/USART	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad	384 K	A/D 48x12b SAR	216-TEQFP (24x24)	100 MHz 240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABEBQ1AESGS	128 K	4.06 MB	FLASH	External Internal	DMA I2S LVD Temp Sensor WDT	CANbus Ethernet I2C LINbus SPI UART/USART	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad	384 K	A/D 48x12b SAR	216-TEQFP (24x24)	100 MHz 240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABFBQ1AESGS	128 K	4.06 MB	FLASH	External Internal	DMA I2S LVD Temp Sensor WDT	CANbus Ethernet I2C LINbus SPI UART/USART	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad	384 K	A/D 48x12b SAR	216-TEQFP (24x24)	100 MHz 240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABABQ1AESGST	128 K	4.063 MB	FLASH		DMA I2S LVD Temp Sensor WDT	DMA I2S LVD Temp Sensor WDT	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad 216-QFP	384 K		216-TEQFP (24x24) 216-TQFP	240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABHBQ1AESGS	128 K	4.063 MB	FLASH		DMA I2S LVD Temp Sensor WDT	DMA I2S LVD Temp Sensor WDT	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad 216-QFP	384 K		216-TEQFP (24x24) 216-TQFP	240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABGBQ1AESGS	128 K	4.063 MB	FLASH		DMA I2S LVD Temp Sensor WDT	DMA I2S LVD Temp Sensor WDT	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad 216-QFP	384 K		216-TEQFP (24x24) 216-TQFP	240 MHz	-40 °C	105 °C	Surface Mount
INFINEON CYT3DLABGBQ1AESGST	128 K	4.063 MB	FLASH		DMA I2S LVD Temp Sensor WDT	DMA I2S LVD Temp Sensor WDT	ARM® Cortex®-M0+ ARM® Cortex®-M7F	108	5.5 V	2.7 V	32 Bit	Dual-Core	216-LQFP Exposed Pad 216-QFP	384 K		216-TEQFP (24x24) 216-TQFP	240 MHz	-40 °C	105 °C	Surface Mount
