LAQ Series

Manufacturer: Nichicon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 390UF 200 VOLTS 0.2

Part	Package / Case	Size / Dimension [diameter]	Size / Dimension [diameter]	Lifetime @ Temp.	Applications	Polarization	Tolerance	Ripple Current @ High Frequency	Lead Spacing	Lead Spacing	Capacitance	Ripple Current @ Low Frequency	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Size / Dimension
Nichicon LAQ2D391MELZ35	Radial Can - Snap-In	0.866 "	22 mm	2000 Hrs	General Purpose	Polar	20 %	1.62 A	0.394 in	10 mm	390 µF	1.35 A	Through Hole	105 ░C	-25 °C	200 VDC	37 mm	1.457 in
Nichicon LAQ2G820MELA25	Radial Can - Snap-In	0.984 "	25 mm	2000 Hrs	General Purpose	Polar	20 %	667 mA	0.394 in	10 mm	0.082 mF	580 mA	Through Hole	105 ░C	-25 °C	400 V			1.063 in	27 mm
Nichicon LAQ2P391MELZ45	Radial Can - Snap-In	0.866 "	22 mm	2000 Hrs	General Purpose	Polar	20 %	1.62 A	0.394 in	10 mm	390 µF	1.35 A	Through Hole	105 ░C	-25 °C	220 V			1.85 in	47 mm
Nichicon LAQ2D471MELA30	Radial Can - Snap-In	0.984 "	25 mm	2000 Hrs	General Purpose	Polar	20 %	1.74 A	0.394 in	10 mm	470 µF	1.45 A	Through Hole	105 ░C	-25 °C	200 VDC		1.26 in			32 mm
Nichicon LAQ2G221MELC30	Radial Can - Snap-In	1.378 "	35 mm	2000 Hrs	General Purpose	Polar	20 %	1.426 A	0.394 in	10 mm	220 µF	1.24 A	Through Hole	105 ░C	-25 °C	400 V		1.26 in			32 mm
Nichicon LAQ2P101MELZ20	Radial Can - Snap-In	0.866 "	22 mm	2000 Hrs	General Purpose	Polar	20 %	600 mA	0.394 in	10 mm	100 µF	500 mA	Through Hole	105 ░C	-25 °C	220 V						0.866 in	22 mm
Nichicon LAQ2G271MELB40	Radial Can - Snap-In	1.181 "		2000 Hrs	General Purpose	Polar	20 %	1.495 A	0.394 in	10 mm	270 µF	1.3 A	Through Hole	105 ░C	-25 °C	400 V		1.654 in			42 mm			30 mm
