Optoelectronics
HLMP-P505-G0011
ActiveBroadcom Limited
LED GREEN CLEAR GULL WING SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsOption 11,12,21,22,31,32,1L,1S,2L,2S
Optoelectronics
HLMP-P505-G0011
ActiveBroadcom Limited
LED GREEN CLEAR GULL WING SMD
Deep-Dive with AI
DocumentsOption 11,12,21,22,31,32,1L,1S,2L,2S
Technical Specifications
Parameters and characteristics for this part
| Specification | HLMP-P505-G0011 |
|---|---|
| Color | Green |
| Configuration | Standard |
| Current - Test | 10 mA |
| Height (Max) [Max] [z] | 2.44 mm |
| Lens Color | Colorless |
| Lens Size [diameter] | 1.78 mm |
| Lens Transparency | Clear |
| Millicandela Rating | 6.3 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, Gull Wing |
| Size / Dimension [x] | 2.09 mm |
| Size / Dimension [y] | 2.21 mm |
| Supplier Device Package | Gull Wing |
| Viewing Angle | 125 ° |
| Voltage - Forward (Vf) (Typ) | 2.1 V |
| Wavelength - Dominant | 569 nm |
| Wavelength - Peak | 565 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.71 | |
| 10 | $ 1.78 | |||
| 100 | $ 1.31 | |||
| 500 | $ 1.12 | |||
| Digi-Reel® | 1 | $ 2.71 | ||
| 10 | $ 1.78 | |||
| 100 | $ 1.31 | |||
| 500 | $ 1.12 | |||
| Tape & Reel (TR) | 1500 | $ 1.04 | ||
| 3000 | $ 0.99 | |||
| 4500 | $ 0.97 | |||
| 7500 | $ 0.95 | |||
| 10500 | $ 0.94 | |||
Description
General part information
HLMP-P505 Series
Green 569nm LED Indication - Discrete 2.1V 2-SMD, Gull Wing
