PI3305-20-EVAL1

Obsolete

EVAL BD PI3305-20

Search across all available documentation for this part.

Development Boards, Kits, Programmers

Obsolete

EVAL BD PI3305-20

Technical Specifications

Parameters and characteristics for this part

Specification	PI3305-20-EVAL1

Board Type	Fully Populated
Contents	Board(s)
Current - Output	8 A
Frequency - Switching	1.5 MHz
Main Purpose	DC/DC, Step Down
Outputs and Type	1
Outputs and Type	Non-Isolated, 1 Non-Isolated Output
Regulator Topology	Buck
Supplied Contents	Board(s)
Utilized IC / Part	PI3305-20
Voltage - Input [Max]	36 V
Voltage - Input [Min]	20.4 V
Voltage - Output	15 V

Part	Outputs and Type	Outputs and Type	Board Type	Supplied Contents	Frequency - Switching	Regulator Topology	Main Purpose	Current - Output	Voltage - Input [Max]	Voltage - Input [Min]	Contents	Voltage - Output	Utilized IC / Part
Vicor Corporation PI3305-20-EVAL1	1	1 Non-Isolated Output Non-Isolated	Fully Populated	Board(s)	1.5 MHz	Buck	DC/DC Step Down	8 A	36 V	20.4 V	Board(s)	15 V	PI3305-20

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	0	$ 53.36

General part information

PI3305-20 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
