Specification	SNP3GHS0C2

Color	Black
Features	Heat Stabilized, Impact Resistant
Length [Max]	0.805 in
Length [Max]	20.45 mm
Length [Min]	14.4 mm
Length [Min]	0.567 in
Material	Polyamide (PA66), Nylon 6/6, Glass Filled
Material Flammability Rating	UL94 HB
Material Thickness	1.78 mm
Material Thickness	0.07 in
Opening Size [Max]	0.45 in
Opening Size [Max]	11.43 mm
Opening Size [Min]	10.06 mm
Opening Size [Min]	0.396 "
Type	Clamp, Hose
Type Attributes	Push-Fit
Width	0.234 in
Width	5.94 mm

SNP3GH Series

Part	Material Thickness	Material Thickness	Material	Type Attributes	Opening Size [Min]	Opening Size [Max]	Opening Size [Max]	Opening Size [Min]	Width	Width	Features	Type	Color	Length [Min]	Length [Max]	Length [Max]	Length [Min]	Material Flammability Rating
HELLERMANNTYTON SNP3GHS0M4	1.78 mm	0.07 in	Polyamide (PA66) Nylon 6/6 Glass Filled	Push-Fit	10.06 mm	0.45 in	11.43 mm	0.396 "	0.234 in	5.94 mm	Heat Stabilized Impact Resistant	Clamp Hose	Black	14.4 mm	0.805 in	20.45 mm	0.567 in	UL94 HB
HELLERMANNTYTON SNP3GHS0C2	1.78 mm	0.07 in	Polyamide (PA66) Nylon 6/6 Glass Filled	Push-Fit	10.06 mm	0.45 in	11.43 mm	0.396 "	0.234 in	5.94 mm	Heat Stabilized Impact Resistant	Clamp Hose	Black	14.4 mm	0.805 in	20.45 mm	0.567 in	UL94 HB

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
