205714-7
Connectors, Interconnects

205714-7

Active
TE Connectivity Raychem Cable Protection

37 PLUG SP/MS STD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsProduct Change Notice ENDatasheet+3
205714-7
Connectors, Interconnects

205714-7

Active
TE Connectivity Raychem Cable Protection

37 PLUG SP/MS STD

Deep-Dive with AI

DocumentsProduct Change Notice ENDatasheet+3

Technical Specifications

Parameters and characteristics for this part

Specification205714-7
ColorBlack
Connector StyleD-Sub
Connector TypePlug, Male Pins
Contact FinishGold
Contact Finish Thickness0.76 Ám
Contact Finish Thickness30 Áin
Contact MaterialBrass
Contact TypeSignal
Current Rating (Amps)6 A
Dielectric MaterialPolybutylene Terephthalate (PBT), Glass Filled
Flange FeatureHousing/Shell (Unthreaded)
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Positions37
Number of Rows2
Operating Temperature [Max]105 ░C
Operating Temperature [Min]-55 °C
Shell Material, FinishSteel, Yellow Chromate Plated Zinc
Shell Size, Connector Layout4 (DC, C)
TerminationSolder
Voltage Rating125 VDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 14.66
14$ 14.36
28$ 13.97
56$ 13.44
NewarkEach 100$ 15.38
250$ 14.74
500$ 14.09

Description

General part information

AMPLIMITE HD-20 Series

D-Sub Standard Connectors 37P PLUG TIN
