1586161-1
ActiveTE Connectivity Raychem Cable Protection
02P UMNL HDR 94VO NDH
Deep-Dive with AI
Search across all available documentation for this part.
Connectors, Interconnects
1586161-1
ActiveTE Connectivity Raychem Cable Protection
02P UMNL HDR 94VO NDH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 1586161-1 |
|---|---|
| Applications | General Purpose |
| Connector Type | Header |
| Contact Finish - Post | Tin |
| Contact Length - Post | 3.94 mm |
| Contact Length - Post | 0.155 " |
| Contact Material | Phosphor Bronze |
| Contact Shape | Circular |
| Contact Type | Male Pin |
| Fastening Type | Locking Ramp |
| Insulation Color | White |
| Insulation Height | 0.55 in |
| Insulation Height | 13.97 mm |
| Insulation Material | Polyamide (PA), Nylon |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 2 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Pitch - Mating | 6.35 mm |
| Pitch - Mating | 0.25 in |
| Shrouding | Shrouded - 4 Wall |
| Style | Board to Cable/Wire |
| Termination | Solder |
| Voltage Rating | 600 VAC |
