Specification	1814WB 010500

Cable Type	Multi-Pair
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	30 AWG
Conductor Strand [custom]	7
Features	Drain Wire, Water-Blocked, UV Resistant
Jacket (Insulation) Diameter [diameter]	9.2 mm
Jacket (Insulation) Diameter [diameter]	0.362 in
Jacket (Insulation) Material	High Density Polyethylene (HDPE)
Jacket (Insulation) Thickness	0.03 in
Jacket (Insulation) Thickness	0.762 mm
Jacket Color	Black
Length	152.4 m
Length	500 ft
Number of Conductors	4
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 ░C
Shield Coverage	100 %
Shield Material	Aluminum, Polyester
Shield Type	Foil
Usage	Audio
Voltage	300 VDC
Wire Gauge	22 AWG

1814WB Series

Part	Shield Material	Shield Coverage	Jacket Color	Usage	Conductor Insulation	Wire Gauge	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Voltage	Conductor Strand [custom]	Conductor Strand [custom]	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Features	Length	Length	Jacket (Insulation) Material	Number of Conductors	Operating Temperature [Min]	Operating Temperature [Max]	Shield Type
Belden Inc. 1814WB 010500	Aluminum Polyester	100 %	Black	Audio	Polypropylene (PP)	22 AWG	9.2 mm	0.362 in	Copper Tinned	300 VDC	30 AWG	7	Multi-Pair	0.03 in	0.762 mm	Drain Wire UV Resistant Water-Blocked	152.4 m	500 ft	High Density Polyethylene (HDPE)	4	-20 ░C	60 °C	Foil

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 (2 Pair) Conductor Multi-Pair Cable Black 22 AWG Foil 500.0' (152.4m)
