HEATSINK FORGED BLK ANO TOP MNT

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsA01 Laminating Adhesive Datasheet

Fans, Blowers, Thermal Management

AER23-23-15CB/A01

Active

CTS Thermal Management Products

HEATSINK FORGED BLK ANO TOP MNT

Deep-Dive with AI

DocumentsA01 Laminating Adhesive Datasheet

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AER23-23-15CB/A01

Attachment Method	Thermal Tape, Adhesive (Included)
Fin Height	14.6 mm
Fin Height [custom]	0.575 in
Length	0.89 in
Length	22.61 mm
Material	Aluminum Alloy
Material Finish	Black Anodized
Package Cooled	LGA, CPU, ASIC, BGA
Shape	Square, Fins
Shelf Life	24 Months
Thermal Resistance @ Forced Air Flow	4.22 °C/W
Thermal Resistance @ Natural	13.72 °C/W
Type	Top Mount
Width [x]	0.89 in
Width [x]	22.61 mm

AER23 Series

Part	Shelf Life	Thermal Resistance @ Natural	Shape	Thermal Resistance @ Forced Air Flow	Material	Package Cooled	Fin Height	Fin Height	Type	Material Finish	Attachment Method	Length	Length	Width [x]	Width [x]	Fin Height [z]	Fin Height [z]	Fin Height [custom]	Fin Height [custom]	Fin Height [custom]	Fin Height [custom]
CTS Thermal Management Products AER23-23-18CB/A01	24 Months	13.42 °C/W	Fins Square	3.92 °C/W	Aluminum Alloy	ASIC BGA CPU LGA	0.693 in	17.6 mm	Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm
CTS Thermal Management Products AER23-23-21CB/A01	24 Months	12.92 °C/W	Fins Square	3.72 °C/W	Aluminum Alloy	ASIC BGA CPU LGA	0.811 in	20.6 mm	Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm
CTS Thermal Management Products AER23-23-28CB/A01	24 Months	11.62 °C/W	Fins Square	3.12 °C/W	Aluminum Alloy	ASIC BGA CPU LGA			Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm	27.6 mm	1.087 in
CTS Thermal Management Products AER23-23-33CB/A01	24 Months	10.82 °C/W	Fins Square	2.82 °C/W	Aluminum Alloy	ASIC BGA CPU LGA	1.283 in	32.6 mm	Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm
CTS Thermal Management Products AER23-23-23CB/A01	24 Months	12.52 °C/W	Fins Square	3.52 °C/W	Aluminum Alloy	ASIC BGA CPU LGA			Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm			22.61 mm	0.89 in
CTS Thermal Management Products AER23-23-12CB/A01	24 Months	14.12 °C/W	Fins Square	4.62 °C/W	Aluminum Alloy	ASIC BGA CPU LGA			Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm					0.457 in	11.6 mm
CTS Thermal Management Products AER23-23-15CB/A01	24 Months	13.72 °C/W	Fins Square	4.22 °C/W	Aluminum Alloy	ASIC BGA CPU LGA		14.6 mm	Top Mount	Black Anodized	Thermal Tape Adhesive (Included)	0.89 in	22.61 mm	0.89 in	22.61 mm					0.575 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	0	$ 5.16
	Tray	300	$ 5.16

Description

General part information

AER23 Series

Heat Sink Assorted (BGA, LGA, CPU, ASIC...) Aluminum Alloy Top Mount
