Cables, Wires

AT-K-26-10-B/1000

Active

Assmann WSW Components

CABLE MOD FLAT 10COND BLK

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

Cables, Wires

AT-K-26-10-B/1000

Active

Assmann WSW Components

CABLE MOD FLAT 10COND BLK

Deep-Dive with AI

DocumentsDatasheet

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AT-K-26-10-B/1000

Cable Height	0.097 in
Cable Height	2.46 mm
Cable Type	Straight
Cable Width	0.425 in
Cable Width	10.8 mm
Conductor Material	Copper, Bare
Conductor Strand [custom]	7
Conductor Strand [diameter]	0.0063 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Black
Length	304.8 m
Length	1000 ft
Number of Conductors [custom]	10
Shielding	Unshielded
Wire Gauge	26 AWG

AT-K-26 Series

Part	Conductor Material	Voltage	Shielding	Jacket (Insulation) Material	Length	Length	Jacket Color	Cable Height	Cable Height	Cable Type	Cable Width	Cable Width	Conductor Strand [diameter]	Conductor Strand [custom]	Wire Gauge	Number of Conductors [custom]	Length [x]	Length [x]	Number of Conductors
Assmann WSW Components AT-K-26-8-S/100	Copper Bare	30 V	Unshielded	Poly-Vinyl Chloride (PVC)	30.5 m	100 '	Silver	0.097 in	2.46 mm	Straight	0.346 in	8.8 mm	0.0063 in	7	26 AWG	8
Assmann WSW Components AT-K-26-8-B/500	Copper Bare	30 V	Unshielded	Poly-Vinyl Chloride (PVC)			Black	0.097 in	2.46 mm	Straight	0.346 in	8.8 mm	0.0063 in	7	26 AWG	8	152.4 m	500 ft
Assmann WSW Components AT-K-26-6-S/1000	Copper Bare		Unshielded	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	Silver	0.097 in	2.46 mm	Straight	0.267 in	6.8 mm	0.0063 in	7	26 AWG				6
Assmann WSW Components AT-K-26-8-B/1000	Copper Bare	30 V	Unshielded	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	Black	0.097 in	2.46 mm	Straight	0.346 in	8.8 mm	0.0063 in	7	26 AWG	8
Assmann WSW Components AT-K-26-8-B/100	Copper Bare	30 V	Unshielded	Poly-Vinyl Chloride (PVC)	30.5 m	100 '	Black	0.097 in	2.46 mm	Straight	0.346 in	8.8 mm	0.0063 in	7	26 AWG	8
Assmann WSW Components AT-K-26-6-B/500	Copper Bare		Unshielded	Poly-Vinyl Chloride (PVC)			Black	0.097 in	2.46 mm	Straight	0.267 in	6.8 mm	0.0063 in	7	26 AWG		152.4 m	500 ft	6
Assmann WSW Components AT-K-26-8-W/100	Copper Bare	30 V	Unshielded	Poly-Vinyl Chloride (PVC)	30.5 m	100 '	White	0.097 in	2.46 mm	Straight	0.346 in	8.8 mm	0.0063 in	7	26 AWG	8
Assmann WSW Components AT-K-26-4-B/500	Copper Bare		Unshielded	Poly-Vinyl Chloride (PVC)			Black	0.097 in	2.46 mm	Straight	0.189 in	4.8 mm	0.0063 in	7	26 AWG		152.4 m	500 ft	4
Assmann WSW Components AT-K-26-10-B/1000	Copper Bare		Unshielded	Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	Black	0.097 in	2.46 mm	Straight	0.425 in	10.8 mm	0.0063 in	7	26 AWG	10
Assmann WSW Components AT-K-26-10-B/100	Copper Bare		Unshielded	Poly-Vinyl Chloride (PVC)	30.5 m	100 '	Black	0.097 in	2.46 mm	Straight	0.425 in	10.8 mm	0.0063 in	7	26 AWG	10

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	26000	$ 0.31
	Spool	1000	$ 0.19

Description

General part information

AT-K-26 Series

10 Conductor Modular Straight Cable Black 1000' (304.80m)
