Switches

13SX1-T

Active

SWITCH SNAP ACTION N.O./N.C. SPDT PLUNGER SOLDER 1A 250VAC 30VDC 0.97N SCREW MOUNT

Search across all available documentation for this part.

Switches

Active

SWITCH SNAP ACTION N.O./N.C. SPDT PLUNGER SOLDER 1A 250VAC 30VDC 0.97N SCREW MOUNT

Technical Specifications

Parameters and characteristics for this part

Part	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Circuit	Termination Style	Voltage Rating - AC	Switch Function	Operating Position	Operating Position	Pretravel	Pretravel	Release Force	Actuator Type	Voltage Rating - DC	Differential Travel	Differential Travel	Overtravel [custom]	Overtravel [custom]	Operating Force	Mechanical Life
Honeywell Sensing and Productivity Solutions 13SX1-T	1 A	-55 C	125 °C	Chassis Mount	SPDT	Solder Turret	125 V	On-Mom	8.13 mm	0.32 "	0.02 in	0.5 mm	21 gf	Round (Pin Plunger)	30 V	0.001 in	0.025 mm	0.004 in	0.1 mm	99 gf	10000000 Cycles

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	200	$ 37.55
	N/A	0	$ 51.06
Newark	Each	1	$ 43.45

General part information

Switch SPDT Chassis Mount
