NORCOMP 181-M26-213R141
Connectors, Interconnects

181-M62-213R141

Active
NorComp Inc.

D SUB CONNECTOR, HD62, RECEPTACLE, 181 M SERIES, 62 CONTACTS, DC, THROUGH HOLE

Deep-Dive with AI

Search across all available documentation for this part.

Documents3D Product Image ENDrawing EN+3
NORCOMP 181-M26-213R141
Connectors, Interconnects

181-M62-213R141

Active
NorComp Inc.

D SUB CONNECTOR, HD62, RECEPTACLE, 181 M SERIES, 62 CONTACTS, DC, THROUGH HOLE

Deep-Dive with AI

Documents3D Product Image ENDrawing EN+3

Technical Specifications

Parameters and characteristics for this part

Specification181-M62-213R141
Backset Spacing8.89 mm
Backset Spacing0.35 in
ColorBlack
Connector StyleD-Sub, High Density
Connector TypeReceptacle, Female Sockets
Contact FinishGold
Contact Finish ThicknessFlash
Contact MaterialBrass
Contact TypeSignal
Current Rating (Amps)5 A
Dielectric MaterialPolyamide (PA6T), Nylon 6T
FeaturesBoard Lock, Shielded
Flange FeatureHousing/Shell
Flange Feature4-40
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole, Panel Mount, Right Angle
Number of Positions62
Number of Rows [custom]3
Operating Temperature [Max]105 ░C
Operating Temperature [Min]-55 C
Shell Material, FinishSteel, Nickel Plated
Shell Size, Connector LayoutC, DC
Shell Size, Connector Layout4
TerminationSolder

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyN/A 0$ 31.85
Tray 1$ 29.09
10$ 25.48
25$ 24.37
40$ 23.59
80$ 22.80
240$ 21.54
440$ 20.92
NewarkEach 10$ 26.63
100$ 23.05
500$ 21.18
1000$ 20.71

Description

General part information

181-M62 Series

62 Position D-Sub, High Density Receptacle, Female Sockets Connector
