Switches

500SSP3S1M2REB

Active

E-Switch

SWITCH: SLIDE; POS: 3; SP3T; 0.02A/20VAC; 0.02A/20VDC; ON-OFF-ON

Deep-Dive with AI

Search across all available documentation for this part.

Documents500SSP3S1M2REB.pdf

Switches

500SSP3S1M2REB

Active

E-Switch

SWITCH: SLIDE; POS: 3; SP3T; 0.02A/20VAC; 0.02A/20VDC; ON-OFF-ON

Deep-Dive with AI

Documents500SSP3S1M2REB.pdf

Specifications Series Pricing Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	500SSP3S1M2REB

Actuator Length [x]	5.08 mm
Actuator Material	Polyamide (PA), Nylon
Actuator Type	Standard
Circuit	SPDT
Contact Finish	Gold
Contact Material	Copper Alloy
Contact Timing	Not Specified
Current Rating (Amps)	0.4 VA
Electrical Life	30000 Cycles
Features	Epoxy Sealed Terminals
Mechanical Life	30000 Steps
Mounting Type	Panel Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-30 ░C
Switch Function	On-Off-On
Switch Travel	2.16 mm
Termination Style	PC Pin
Voltage Rating - AC	20 V
Voltage Rating - DC	20 V

500 Series

Part	Switch Function	Actuator Length [x]	Features	Voltage Rating - DC	Current Rating (Amps)	Mounting Type	Voltage Rating - AC	Operating Temperature [Max]	Operating Temperature [Min]	Contact Timing	Contact Finish	Contact Material	Termination Style	Circuit	Actuator Type	Mechanical Life	Actuator Material	Electrical Life	Switch Travel
E-Switch 500SSP3S3M7QEA	On-Off-On	9.04 mm	Epoxy Sealed Terminals	28 V	5 A	Right Angle Through Hole Vertical	120 V	85 °C	-30 ░C	Not Specified	Silver	Copper Alloy	PC Pin	SPDT	Standard
E-Switch 500SSP3S1M2REB	On-Off-On	5.08 mm	Epoxy Sealed Terminals	20 V	0.4 VA	Panel Mount	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	PC Pin	SPDT	Standard	30000 Steps	Polyamide (PA) Nylon	30000 Cycles	2.16 mm
E-Switch 500SDP1S4M1REB	On-On	3.56 mm		20 V	0.4 VA	Panel Mount	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	Solder Lug	DPDT	Standard
E-Switch 500SDP1S3M2QEA	On-On	9.4 mm	Epoxy Sealed Terminals	28 V	5 A	Through Hole	120 V	85 °C	-30 ░C	Not Specified	Silver	Copper Alloy	PC Pin	DPDT	Standard
E-Switch 500SSP1S1M1QEA	On-On	5.08 mm	Epoxy Sealed Terminals	28 V	5 A	Panel Mount	120 V	85 °C	-30 ░C	Not Specified	Silver	Copper Alloy	Solder Lug	SPDT	Standard
E-Switch 500SSP1S2M7REA	On-On	6.88 mm	Epoxy Sealed Terminals	20 V	0.4 VA	Right Angle Through Hole Vertical	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	PC Pin	SPDT	Standard
E-Switch 500SSP1S2M6REA	On-On	6.88 mm	Epoxy Sealed Terminals	20 V	0.4 VA	Right Angle Through Hole	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	PC Pin	SPDT	Standard
E-Switch 500SSP3S2M7QEA	On-Off-On	6.88 mm	Epoxy Sealed Terminals	28 V	5 A	Right Angle Through Hole Vertical	120 V	85 °C	-30 ░C	Not Specified	Silver	Copper Alloy	PC Pin	SPDT	Standard	30000 Steps	Polyamide (PA) Nylon	30000 Cycles	2.16 mm
E-Switch 500SSP1S3M7REA	On-On	9.04 mm	Epoxy Sealed Terminals	20 V	0.4 VA	Right Angle Through Hole Vertical	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	PC Pin	SPDT	Standard
E-Switch 500SDP1S1M2REA	On-On	5.08 mm	Epoxy Sealed Terminals	20 V	0.4 VA	Through Hole	20 V	85 °C	-30 ░C	Not Specified	Gold	Copper Alloy	PC Pin	DPDT	Standard
