Specification	SNP3410K2

Color	White
Length [Max]	49.94 mm
Length [Max]	1.966 in
Length [Min]	1.186 in
Length [Min]	30.12 mm
Material	Polyacetal (POM)
Material Flammability Rating	UL94 HB
Material Thickness	1.73 mm
Material Thickness	0.068 in
Opening Size [Max]	39.78 mm
Opening Size [Max]	1.566 in
Opening Size [Min]	1.338 in
Opening Size [Min]	33.98 mm
Type	Clamp, Hose
Type Attributes	Push-Fit
Width [x]	0.292 in
Width [x]	7.42 mm

SNP3410 Series

Part	Color	Type Attributes	Material Flammability Rating	Material	Material Thickness	Material Thickness	Length [Max]	Length [Min]	Length [Min]	Length [Max]	Type	Width [x]	Width [x]	Opening Size [Max]	Opening Size [Max]	Opening Size [Min]	Opening Size [Min]
HELLERMANNTYTON SNP3410K2	White	Push-Fit	UL94 HB	Polyacetal (POM)	1.73 mm	0.068 in	49.94 mm	1.186 in	30.12 mm	1.966 in	Clamp Hose	0.292 in	7.42 mm	39.78 mm	1.566 in	1.338 in	33.98 mm
