Technical Specifications
Parameters and characteristics for this part
| Specification | EL852(S)(TU)(D)-V |
|---|---|
| Current - DC Forward (If) (Max) [Max] | 60 mA |
| Current - Output / Channel | 150 mA |
| Current Transfer Ratio (Max) | 15000 % |
| Current Transfer Ratio (Min) | 1000 % |
| Input Type | DC |
| Mounting Type | Surface Mount |
| Number of Channels [custom] | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -55 C |
| Output Type | Darlington |
| Package / Case | 4-SMD, Gull Wing |
| Rise / Fall Time (Typ) | 300 µs |
| Rise / Fall Time (Typ) [Max] | 100 µs |
| Supplier Device Package | 4-SMD |
| Vce Saturation (Max) [Max] | 1.2 V |
| Voltage - Output (Max) [Max] | 350 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | N/A | 0 | $ 0.00 | |
Description
General part information
EL852 Series
Optoisolator Darlington Output 5000Vrms 1 Channel 4-SMD
