Specification	SNP8GHS0M4

Color	Black
Features	Heat Stabilized, Impact Resistant
Length [Max]	0.981 in
Length [Max]	24.92 mm
Length [Min]	16.59 mm
Length [Min]	0.653 in
Material	Polyamide (PA66), Nylon 6/6, Glass Filled
Material Flammability Rating	UL94 HB
Material Thickness	1.78 mm
Material Thickness	0.07 in
Opening Size [Max]	0.599 in
Opening Size [Max]	15.21 mm
Opening Size [Min]	0.524 in
Opening Size [Min]	13.31 mm
Type	Clamp, Hose
Type Attributes	Push-Fit
Width [x]	0.233 in
Width [x]	5.92 mm

SNP8GH Series

Part	Opening Size [Max]	Opening Size [Min]	Opening Size [Max]	Opening Size [Min]	Length [Min]	Length [Max]	Length [Min]	Length [Max]	Width [x]	Width [x]	Color	Material Thickness	Material Thickness	Type	Type Attributes	Features	Material Flammability Rating	Material
HELLERMANNTYTON SNP8GHS0M4	0.599 in	0.524 in	15.21 mm	13.31 mm	16.59 mm	0.981 in	0.653 in	24.92 mm	0.233 in	5.92 mm	Black	1.78 mm	0.07 in	Clamp Hose	Push-Fit	Heat Stabilized Impact Resistant	UL94 HB	Polyamide (PA66) Nylon 6/6 Glass Filled
HELLERMANNTYTON SNP8GHS0C2	0.599 in	0.524 in	15.21 mm	13.31 mm	16.59 mm	0.981 in	0.653 in	24.92 mm	0.233 in	5.92 mm	Black	1.78 mm	0.07 in	Clamp Hose	Push-Fit	Heat Stabilized Impact Resistant	UL94 HB	Polyamide (PA66) Nylon 6/6 Glass Filled

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
