Relays

GN325DSR

Active

SSR RELAY 3PST-NO 25A 48-530V

Search across all available documentation for this part.

Relays

Active

SSR RELAY 3PST-NO 25A 48-530V

Technical Specifications

Parameters and characteristics for this part

Part	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Load [Max]	Voltage - Load [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Circuit	Approval Agency	Output Type	Termination Style	Load Current	Mounting Type
Sensata-Crydom GN325DLZ	32 VDC	4 V	600 V	48 V	80 °C	-40 C	3PST-NO (3 Form A)	CE CSA TUV UR	AC Zero Cross	Screw Terminal	25 A	DIN Rail
Sensata-Crydom GN325DSR	32 VDC	4 V			80 °C	-40 C	3PST-NO (3 Form A)	CE CSA TUV UR	AC	Screw Terminal	25 A	DIN Rail
Sensata-Crydom GN325DLR	32 VDC	4 V	600 V	48 V	80 °C	-40 C	3PST-NO (3 Form A)	CE CSA TUV UR	AC	Screw Terminal	25 A	DIN Rail
Sensata-Crydom GN325DSZ	32 VDC	4 V			80 °C	-40 C	3PST-NO (3 Form A)	CE CSA TUV UR	AC Zero Cross	Screw Terminal	25 A	DIN Rail

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Solid State 3PST-NO (3 Form A)
