M80-4121005
ActiveHarwin Inc.
5+5 POS. FEMALE DIL VERTICAL SMT CONN. NO JACKSCREWS ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | M80-4121005 |
|---|---|
| Applications | Automotive, Military, General Purpose |
| Connector Type | Receptacle |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating | 12 Áin |
| Contact Finish Thickness - Mating | 0.3 Ám |
| Contact Finish Thickness - Post | 10 Áin |
| Contact Finish Thickness - Post | 0.25 çm |
| Contact Material | Beryllium Copper |
| Contact Shape | Circular |
| Contact Type | Female Socket |
| Features | Mating Flange, Polarizing Key |
| Insulation Color | Black |
| Insulation Height | 5.6 mm |
| Insulation Height | 0.22 in |
| Insulation Material | Polyphenylene Sulfide (PPS), Glass Filled |
| Mated Stacking Heights | 7.98 mm, 7.7 mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Surface Mount |
| Number of Positions | 10 |
| Number of Positions Loaded | All |
| Number of Rows [custom] | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 C |
| Pitch - Mating | 0.079 " |
| Pitch - Mating | 2 mm |
| Row Spacing - Mating | 2 mm |
| Row Spacing - Mating | 0.079 in |
| Style | Cable, Board to Board |
| Termination | Solder |
| Voltage Rating | 120 VDC |
| Part | Insulation Material | Contact Material | Contact Shape | Applications | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Voltage Rating | Mated Stacking Heights | Row Spacing - Mating | Row Spacing - Mating | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Mounting Type | Contact Finish - Post | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Connector Type | Material Flammability Rating | Number of Positions | Insulation Color | Number of Rows [custom] | Contact Finish - Mating | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Style | Number of Positions Loaded | Contact Type | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 10 Áin | 0.25 çm | 120 VDC | 7.7 mm 7.98 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Gold | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | 10 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | |
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 137.8 Áin | 3.5 Ám | 120 VDC | 7.7 mm 7.95 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Tin | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | 26 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | |
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 137.8 Áin | 3.5 Ám | 120 VDC | 7.7 mm 7.98 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Tin | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | 8 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | |
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 137.8 Áin | 3.5 Ám | 120 VDC | 7.7 mm 7.95 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Tin | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | 10 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | |
 Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 137.8 Áin | 3.5 Ám | 120 VDC | 7.7 mm 7.95 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Tin | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | 50 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | |
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | Beryllium Copper | Circular | Automotive General Purpose Military | 137.8 Áin | 3.5 Ám | 120 VDC | 7.7 mm 7.95 mm | 2 mm | 0.079 in | 5.6 mm | 0.22 in | 0.079 " | 2 mm | Surface Mount | Tin | Mating Flange Polarizing Key | 12 Áin | 0.3 Ám | Receptacle | UL94 V-0 | Black | 2 | Gold | Solder | -55 C | 125 °C | Board to Board Cable | All | Female Socket | 34 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
M80-412 Series
10 Position Receptacle Connector 0.079" (2.00mm) Surface Mount Gold
