Technical Specifications
Parameters and characteristics for this part
| Specification | SFH 4180S A01 |
|---|---|
| Current - DC Forward (If) (Max) [Max] | 1 A |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 C |
| Orientation | Top View |
| Package / Case | 0606 (1616 Metric) |
| Radiant Intensity (Ie) Min @ If [Min] | 280 mW/sr |
| Type | Infrared (IR) |
| Viewing Angle | 130 ° |
| Voltage - Forward (Vf) (Typ) | 2.95 V |
| Wavelength | 950 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.98 | |
| 10 | $ 2.17 | |||
| 100 | $ 1.69 | |||
| 500 | $ 1.47 | |||
| 1000 | $ 1.40 | |||
| 2000 | $ 1.39 | |||
| Digi-Reel® | 1 | $ 2.98 | ||
| 10 | $ 2.17 | |||
| 100 | $ 1.69 | |||
| 500 | $ 1.47 | |||
| 1000 | $ 1.40 | |||
| 2000 | $ 1.39 | |||
| N/A | 2753 | $ 2.98 | ||
| Tape & Reel (TR) | 4000 | $ 1.14 | ||
Description
General part information
SFH4180 Series
Infrared (IR) Emitter 950nm 2.95V 1A 280mW/sr @ 1A (Typ) 130° 0606 (1616 Metric)
