Specification	63SXE68M

Applications	General Purpose
Capacitance	68 µF
ESR (Equivalent Series Resistance)	25 mOhm
Height - Seated (Max) [Max] [z]	0.512 "
Height - Seated (Max) [Max] [z]	13 mm
Lead Spacing	0.197 "
Lead Spacing	5 mm
Lifetime @ Temp.	1000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 C
Package / Case	Radial, Can
Ripple Current @ High Frequency	1.03 A
Ripple Current @ Low Frequency	51.5 mA
Size / Dimension [diameter]	0.394 in
Size / Dimension [diameter]	10 mm
Tolerance	20 %
Type	Polymer
Voltage - Rated	63 V

63SXE Series

Part	Voltage - Rated	Tolerance	Lead Spacing	Lead Spacing	Lifetime @ Temp.	Mounting Type	Applications	ESR (Equivalent Series Resistance)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Size / Dimension [diameter]	Size / Dimension [diameter]	Operating Temperature [Min]	Operating Temperature [Max]	Ripple Current @ Low Frequency	Ripple Current @ High Frequency	Package / Case	Type	Height - Seated (Max) [Max]	Height - Seated (Max)	Height - Seated (Max) [Max]
Panasonic Electronic Components 63SXE68M	63 V	20 %	0.197 "	5 mm	1000 Hrs	Through Hole	General Purpose	25 mOhm	0.512 "	13 mm	68 µF	0.394 in	10 mm	-55 C	125 °C	51.5 mA	1.03 A	Can Radial	Polymer
Panasonic Electronic Components 63SXE100M	63 V	20 %	0.197 "	5 mm	1000 Hrs	Through Hole	General Purpose	25 mOhm	0.512 "	13 mm	100 µF	0.394 in	10 mm	-55 C	125 °C	164 mA	3.28 A	Can Radial	Polymer
Panasonic Electronic Components 63SXE33M	63 V	20 %	0.138 in	3.5 mm	1000 Hrs	Through Hole	General Purpose	25 mOhm			33 ÁF	0.315 in	8 mm	-55 C	125 °C	147.5 mA	2.95 A	Can Radial	Polymer	0.472 in	12 mm
Panasonic Electronic Components 63SXE18M	63 V	20 %	0.138 in	3.5 mm	1000 Hrs	Through Hole	General Purpose	60 mOhms			18 µF	0.315 in	8 mm	-55 C	125 °C	17 mA	340 mA	Can Radial	Polymer	0.276 in		7 mm
Panasonic Electronic Components 63SXE56M	63 V	20 %	0.138 in	3.5 mm	1000 Hrs	Through Hole	General Purpose	25 mOhm			56 µF	0.315 in	8 mm	-55 C	125 °C	147.5 mA	2.95 A	Can Radial	Polymer	0.472 in	12 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

68 µF 63 V Aluminum - Polymer Capacitors Radial, Can 25mOhm 1000 Hrs @ 125°C
