RCPT,2MM,44P,R ANG MT,8AU,3.ST-4-1734531-4
Connectors, Interconnects

4-1734531-4

Active
TE Connectivity Raychem Cable Protection

CONN SOCKET STRIP SKT 44 POS 2MM SOLDER RA SIDE ENTRY THRU-HOLE BOX

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsENG_CD_1734531_D5.pdfAMPMODU 2.0MM PITCH BOARD TO BOARD CONNECTOR.+1
RCPT,2MM,44P,R ANG MT,8AU,3.ST-4-1734531-4
Connectors, Interconnects

4-1734531-4

Active
TE Connectivity Raychem Cable Protection

CONN SOCKET STRIP SKT 44 POS 2MM SOLDER RA SIDE ENTRY THRU-HOLE BOX

Deep-Dive with AI

DocumentsENG_CD_1734531_D5.pdfAMPMODU 2.0MM PITCH BOARD TO BOARD CONNECTOR.+1

Technical Specifications

Parameters and characteristics for this part

Specification4-1734531-4
Connector TypeReceptacle
Contact Finish - MatingGold
Contact Finish - PostTin
Contact Finish Thickness - Mating10 çin
Contact Finish Thickness - Mating0.25 çm
Contact Finish Thickness - Post2.54 µm
Contact Finish Thickness - Post100 µin
Contact Length - Post0.118 in
Contact Length - Post3 mm
Contact MaterialPhosphor Bronze
Contact ShapeSquare
Contact TypeFemale Socket
Fastening TypePush-Pull
Insulation ColorBlack
Insulation Height0.191 in
Insulation Height4.85 mm
Insulation MaterialThermoplastic
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole, Right Angle
Number of Positions44
Number of Positions LoadedAll
Number of Rows2
Operating Temperature [Max]105 ░C
Operating Temperature [Min]-40 °C
Pitch - Mating [x]0.079 in
Pitch - Mating [x]2 mm
Row Spacing - Mating0.079 in
Row Spacing - Mating2 mm
TerminationSolder
Voltage Rating250 VAC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyTube 1950$ 4.73
NewarkEach 1000$ 4.89
2500$ 4.39

Description

General part information

AMPMODU 2 mm Series

Board to Board & Mezzanine Connectors AMPMODU 2.00mm 28p R/A 8u
