Parameters and characteristics for this part
| Specification | 09340060501 |
|---|---|
| Connector Type | Insert |
| Gender | Female |
| Number of Positions | 24 |
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
General part information
Female Insert 24 Position
Technical documentation and resources
| Part | Features | Connector Type | Style | Lock Location | Thread Size | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Number of Positions | Gender | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | Feed Through | Base - Box Mount | Side Entry | Locking Clip (1) on Base Bottom | PG21 | 117 mm | 2.244 " | 2.205 " | 57 mm | 56 mm | 4.606 in | ||||
 HARTING | Insert | 24 | Female | ||||||||||||
HARTING | Cover | Base - Panel Mount | Bottom Entry | Locking Clip (2) on Hood | 113 mm | 1.709 " | 1.138 " | 43.4 mm | 28.9 mm | 4.449 " | |||||
HARTING | Base - Panel Mount | Bottom Entry | Locking Clip (1) on Base Bottom | 113 mm | 1.693 " | 1.138 " | 4.449 " | 28.9 mm | 43 mm | ||||||
 HARTING | Hood | Top Entry | Locking Clip (1) on Base Bottom | PG21 | 93.5 mm | 1.693 " | 1.772 in | 3.681 in | 45 mm | 43 mm | |||||
HARTING | Cable to Cable | Hood - Coupling | Bottom Entry Top or Bottom Entry | Locking Clip (2) on Hood Top | PG21 | 93.5 mm | 1.693 " | 1.866 " | 3.681 in | 47.4 mm | 43 mm | ||||
 HARTING | Cover | Base - Panel Mount | Bottom Entry | Locking Clip (1) on Base Bottom | 113 mm | 1.693 " | 1.138 " | 4.449 " | 28.9 mm | 43 mm |
